Can the HD-6 anchor be used in seismic design category D at 6″ embedment?
Answer · 2 sources
Yes, with conditions. At 6″ embedment in 4,000 psi normal-weight concrete, use the reduced seismic tension value from Table 4 and apply the 0.75 factor per the design flowchart. Special inspection is required.
- SRC 1 · ESR-4211, Table 4, p. 9
- SRC 2 · Seismic design flowchart, Sheet 2 of 3
